Heat Resistant Conveyor Belt

  • Heat Resistant Conveyor Belt
Heat Resistant Conveyor Belt

Heat Resistant Conveyor Belt

  • Model Number:EP100-EP600
  • width: 400-3000mm
  • Thickness: 4-30mm
  • Working Temperature : 0 - 600C
  • Product description:
  • INQUIRY

Heat resistant conveyor belt is made up of high temperature burning layer, transition layer, the organic insulation layer, a strong heat-resistant layer and layer. The rubber surface uses EPDM(Ethylene Propylene Diene Monomer) or SBR(Polymerized Styrene Butadiene Rubber) to make rubber cover respectively; The polyester canvas or canvas with high strength and high permeability can make the strong layer. These will be bonded together through high-temperature vulcanization.


Characteristics:

The heat resistant rubber cover produce porous carbonized stratum as conveyor belt carrying high temperature material, this carbonized stratum has burning resistant function, and  prevent  high temperature from transferring further into belt centre body, so that can protect the internal strength of the heat resistant conveyor belt. Furthermore, the carbonized stratum generates irregular tiny crack during the conveyor belt’s running, which can have a cooling effect for the conveyor belt itself.

Application:

Used in cement plant. Steel and lron factory, metallurgy, coking industry. mainly for conveying coke iron and steel castings cement clinker and high temperature materials Feature: Product selects cotton canvas or EP canvas as skeleton material. Cover rubber and cushion rubber is styrene-butadiene rubber or chlorobutadiene that has good heat resistant work and it is suitable for carrying materials under the temperature of 150℃.

Under the test temperature no more than 100℃.Code T1

Under the test temperature no more than 125℃.Code T2

Under the test temperature no more than 150℃.Code T3

Under the test temperature no more than 175℃.Code T4


Cover’s physical property after aging:

HR CONVEYOR BELT

How to choose right heat resistant conveyor belt according to carrying material:

HR
